New 8.4" LB084S02-TD01 LCD Panel LCD Display Screen
$128.00
Skip to product information
Panel brand: LG. Philipis
Panel model: LB084S02-TD01
Panel type: a-Si TFT-LCD
Panel size: 8.4"(inches)
Display Area: 1170.4x127.8mm
Visual Area: 172.8x130.2mm
Outline Size:189.8x149.4mm
Resolution: 800*600
Display mode: TN, Normally white, transmission type
Surface treatment: Matte, hard-core coating (3H)
Panel Brightness: 250 cd/㎡(Typ.)
Contrast: 500:1 (Typ.)
Display Color: 262K
Response Time: 10/15 (Typ.) (Tr/Td) (ms)
Visual Angle: 65/65/45/60 (Typ.)(CR≥10) (L/R/U/D)
Scanning Frequency:60Hz
Lamp Type: 3S9PWLED
Signal Connector: Parallel RGB (1 ch, 6-bit)
Panel voltage: 3.3/10/19.5/-4.5/4.12V (Typ.)(VCC/AVDD/VGH/VGL/VCOM)
Applications: Industrial control, Industrial Monitor, Maintenance for Mechanic, Medical Imaging Systems, Safety Equipment, Military, Bank Terminal, ATM, Ship, Train LCD Media player, Portable DVD, Car Mobile media etc.
