Original New 8.4 inch AA084XA03 TFT LCD Display Panel 1024*768

Panel brand: Sharp
Panel model: AA084XA03
Panel type: a-Si TFT-LCD, LCD screen
Panel size: 8.4"(inches)
Width Height Rate: 4:3
Display Area: 171.264mm(H)x128.448mm(V)
Visual Area: 174.9mm(H)x132.2mm(V)
Resolution:1024*768
The display mode: TN, Normally white, transmission type
Surface treatment: Matte, hard-core coating (3H)
Panel brightness: 300 cd/㎡(Typ.)
Contrast: 400:1 (Typ.)
Display color: 262K/16.7M   (6-bit / 8-bit)
Response Time: 6/19 (Typ.) (Tr/Td)(ms)
Visual Angle: 65/65/60/50 (Typ.) (CR ≧ 10) (L/R/U/D)
Connector: LVDS(1 ch, 6/8bit)
Panel voltage: 3.3V (Typ.)

Applications: Industrial control, Industrial Monitor, Maintenance for Mechanic, Medical Imaging Systems, Safety Equipment, Military, Bank Terminal, ATM, Ship, Train LCD Media player, Portable DVD, Car Mobile media etc.
