7" LMS700KF05 TFT LCD Display Screen LCD Panel

Panel brand: Samsung
Panel model: LMS700KF05
Panel type: a-Si TFT-LCD, LCD screen
Panel size: 7.0" (inch)
Display Area: 337.9mm x 270.3mm
Width Height Rate: 4:3
Resolution:800*480
The display mode: TN, Normally white, transmission type
Surface treatment: Matte, hard-core coating (3H)
Panel brightness: 350 cd/㎡(Typ.)
Contrast: 400:1 (Typ.)
Display color: 16.7M   (6-bit + Hi-FRC)
Response Time: 25(Typ.) (Tr/Td)(ms)
Visual Angle: 65/65/50/60(Typ.) (CR ≧ 10) (L/R/U/D)
Lamp Type: 8S3P WLED
Singal Type: Parallel RGB (1 ch, 8bit)
Panel voltage: 3.3V (Typ.)

Applications: Industrial control, Industrial Monitor, Maintenance for Mechanic, Medical Imaging Systems, Safety Equipment, Military, Bank Terminal, ATM, Ship, Train LCD Media player, Portable DVD, Car Mobile media etc.
